Reformat

fishnet reformat \
  --alignment <alignments.parquet> \
  --pod5 <raw-signal.pod5> \          # See "Pod5 input" below
  --motifs <motif> \                  # See "Filter arguments" below
  --out <output-file>

After aligning signals to sequences, the alignments consists only of signal indices, not the actual signal chunks. Fishnet provides the reformat command to process previously calculated alignments with the signals into formats that can easily used for further downstream processing or analyses.

Required arguments

Long flag Short flag Type Default Description
--alignment <alignment> -a <alingment> Path(file) - Path to .parquet or .jsonl file produced by fishnet align
--out <out> -o <out> Path (file) - Output path. Extension determines format (.parquet or .tsv)
Long flag Short flag Type Default Description
--pod5 <pod5>... -p <pod5>... Path(s) (file or directory) - POD5 input(s). Required if alignment file lacks raw signal. Multiple allowed

This is required if the alignment file does not contain the raw signal (which is done by setting --output-level 3 in the align command). We recommend not writing the signal to the alignment file to minimize redundancy and file size, since the signals can be easily retrieved again, and the POD5-internal compression is more efficient.

When providing the POD5 data separately for direct RNA data, make sure to also specify the --rna flag.

Filter arguments (one is required):

To reduce the amount of processing required and focus only on bases of interest, the reformat module implements filtering by regions of interest (reference-to-signal only) or motifs of interest (query- & reference-to-signal).

Only parts of a read that overlap with a region of interest are further processed. One of the following options must be chosen for filtering the data:

  1. Manually specifiy region(s) of interest:
  2. --ref-regions <region>...
  3. Each region must follow the <NAME>:<START>-<END> format, where <START> and <END> are 1-based coordinates and inclusive (SAM-style)
  4. Multiple can be specified space-separated
  5. Region(s) of interest in a bed file:
  6. --bed-file <file>
  7. The provided path must point to a bed file following bed-style coordinate conventions (0-based, start inclusive, end exclusive)
  8. Position(s) around a site of interest:
  9. --positions-of-interest <poi>...
  10. Each position must follow the <NAME>:<SITE>-<HALF-SIZE> format, where determines the number of bases up- and downstream from the site that are of interest. <SITE> is 1-based
  11. Multiple can be specified space-separated
  12. Manually specify motif(s) of interest:
  13. --motifs <motif>...
  14. Filter for motif sequence(s). Sequences must contain only 'A', 'C', 'G' and 'T'/'U'
  15. Multiple can be specified space-separated
  16. Provide motif(s) of interest in a fasta file:
  17. --motifs-file <file>
  18. The provided path must point to a fasta file, where each motif must be a separate entry. Sequences must contain only 'A', 'C', 'G' and 'T'/'U'

See CLI - Data filtering for more information about the filtering command-line flags.

Optional arguments

The following arguments are the most relevant optional arguments for most users:

Long flag Short flag Type Default Description
--rna - Flag - Set if direct RNA POD5 file(s) are provided (reverse signal)
--alignment-type <alignment-type> - Enum (reference, query) - Only required if the alignment file contains both query- and reference-to-signal alignments. Set to determine which type will be processed
--strategy <strategy> -s <strategy> Enum (stats, interpolate) stats Processing strategy: compute statistics or interpolate signal (See Reformatting strategies below)
--output-shape <shape> - Enum (melted, exploded, nested) nested Determines output structure (nested only for Parquet) (See Output formats below)
--threads <n> -t <n> Integer 8 Number of parallel threads
--force-overwrite -f Flag - Overwrite existing output file if it exists

For the sake of simplicity, the table shows only a subset of the optional arguments. For an overview of all arguments, see Command line arguments.

Reformatting strategies

There are two reformatting strategies implement:

  1. Base-wise statistics: Calculates statistics that represents the signal assigned to a given base.

    • This is the default strategy. Can be exlicitly set via the --strategy stats flag
    • One or more statistics can be specified via the --stats <stats>... flag (default: mean std dwell).
    • Available statistics are: Mean/Median/Stand. dev. of the signal intensity, dwell time (number of measurements assigned to the base) and signal-to-noise ratio (mean / std. dev.)

  2. Interpolation: Reshapes the signal for each base into a uniform number of samples using linear interpolation.

    • Can be set using the --strategy interpolate flag
    • The number of interpolated samples can be set via the --target-size <target-size> flag (default: 30)

See Reformatting strategies for more details and CLI - Processing strategy for all relevant flags.

Output formats

The reformatted data can be written to compressed parquet or simple TSV format. Since TSV is uncompressed, parquet format is recommended to minimize file size. To account for different downstream processing and analyses, there are three output formats to choose from:

  1. Melted: Long format containing one row for each base. Useful for visualization with ggplot2/seaborn.
  2. Exploded: Wide format containing one row for each read-region pair. All values for all bases appear as separate columns. Here all regions need to have the same length. Useful for machine-learning task, e.g. clustering.
  3. Nested: One row for each read-region pair. Fields store lists or 2D arrays. Only available for parquet output

See Output formats for more details and CLI - I/O settings for all relevant flags.

Examples

Usage examples are provided in Examples.
